Bilstein Suspension Shock Absorber - 27-339022

AS3 Series - Suspension Shock Absorber
Manufacturer: Bilstein
Manufacturer part number: 27-339022
$1,177.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up. Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs. The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately. The AS3 Series shock absorber offers consistent grip and optimal traction.

Application: No Applications

Products specifications

Attribute name Attribute value
Lower Mount Type 1/2in Heim
Upper Mount Type 1/2in Heim
Collapsed Length (IN) 17.58
Extended Length (IN) 22.83
Collapsed Length (mm) 446.5
Body Material Aluminum
Series AS3 Series
Finish Clear Anodized
Valving Identifier Dry Kit (no valving)
Spring Hardware E4-MSG-0096A00
Internal Design Monotube
Segment Motorsports
PartType Shocks / Struts
Adjustable Damping Single Adjustable - Rebound
Piston Type Sold Separately
Body Design Threaded Body Screw Top (Coilover)
Prop 65 - Short Label WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Prop 65 Y/N Y
Spring Seat Included Yes
Piston Diameter 46mm
Stroke/Travel Length (mm) 138.4
Shaft Diameter 14mm
Stroke/Travel Length (IN) 5.45
Extended Length (mm) 580.0
Country of Origin US
Condition New
