AAP_UDA_12
|
EA |
|
AAP_UDA_22
|
1 |
|
AAP_UDA_4
|
55 |
|
Active or Passive Suspension
|
Passive |
|
Add-On Part
|
158508 - COIL SPRING 1400.0300.0700 BLACK, 191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25), 51045 - TOYOTA .25” BUMP STOP SPACER KIT, 252012 - -4 TO -10 HOSE SHIELD KIT, 198000 - 2 PIN COILOVER SPANNER WRENCH KIT, 198001 - BILLET SPANNER WRENCH KIT, 51051 - 05-23 TACOMA/03-24 T4R/07-14 FJ FRONT SWAY BAR LINK KIT |
|
Service Parts
|
611067 - TACOMA/FJ/4RNR LOWER CO BRG/SPCR KIT, 191016 - 7.5" FINNED RESI UPGRADE KIT, 611019 - COILOVER HARDWARE KIT PAIR, 252003 - SEAL INSTALL TOOL 2.5/3.0, 257301 - 7/8 SHAFT 10.25 OAL, 6.00 TRAVEL, 252011 - 2.5 PIGGYBACK/REMOTE RESI/BYPASS REBUILD KIT, 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL, 252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0), 252001 - 2.5 FIXED SPANNER WRENCH |
|
Shaft Diameter
|
0.875 |
|
Shock Absorber Body End Measuring Point
|
Top of Upper Mount Plate |
|
Shock Absorber Rod End Measuring Point
|
Center of Eylet |
|
Spring Color
|
Black |
|
Spring Material
|
Steel |
|
Spring Rate Type
|
Linear |
|
Travel Length
|
4.76 |
|
Upper Mount Type
|
Mounting Plate |
|
Valving Type
|
Digressive |
|
Adjustable Compression
|
No |
|
Adjustable Damping
|
No |
|
Adjustable Rebound
|
No |
|
Adjustable Ride Height
|
Yes |
|
Assembled
|
Yes |
|
Body Diameter
|
2.5 |
|
California Prop 65 Warning
|
Yes |
|
California Proposition 65
|
WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
|
Coil-Over Springs Included
|
Yes |
|
Compressed Length
|
17.42 |
|
Cylinder Color
|
Silver |
|
Cylinder Finish
|
Cadmium Plated |
|
Cylinder Material
|
Steel |
|
Damping Type
|
Oil |
|
Dust Shield Included
|
No |
|
Extended Length
|
22.17 |
|
Front Spring Rate
|
650 |
|
Gas Charged
|
Yes |
|
Grade Type
|
Performance |
|
Includes Bump Stop
|
No |
|
Internal Construction Type
|
Single Tube |
|
Lower Mount Type
|
Eyelet |
|
Material
|
Steel, Aluminum |
|
Maximum Lift
|
3.5 |
|
Maximum Ride Height Raising Distance
|
3.5 |
|
Minimum Lift
|
0 |
|
OEM Wheels & Tires Fitment
|
Yes |
|
Recommended Aftermarket Tires
|
33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required) |
|
Recommended Aftermarket Wheels
|
ICON Alloys - 18x9" w/ 5" Backspace / 0mm Offset, ICON Alloys - 17x8.5 w/ 4.75" Backspace / 0mm Offset, ICON Alloys - 20x9" w/ 5" Backspace / 0mm Offset |
|
Remote Reservoir
|
Yes |
|
Reservoir Style
|
Remote |
|
Self-Leveling
|
No |
|
Country of Origin
|
US |
|
Condition
|
New |
