ICON Vehicle Dynamics Suspension Shock Absorber - 95206R

Name: ICON Vehicle Dynamics Suspension Shock Absorber - 95206R
SKU: 95206R
Price: 1979.95 USD
Availability: OutOfStock

21-25 F-150 RAPTOR PASSENGER REAR 3.0 ZETA RXT RR CDEV

Manufacturer: ICON Vehicle Dynamics

Manufacturer part number: 95206R

Old price: $2,078.95

Price: $1,979.95

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

ICON Vehicle Dynamics is known for its extensive research and development put into every product, the revolutionary outcome of this research is what sets ICON apart from the off-road industry standard. The Ford F-150 Raptor is a unique production truck, designed & built, to bridge the gap between a standard street “pickup truck” and an off-road pre-runner. Since the F-150 Raptor’s release ICON Vehicle Dynamics’ engineers have pushed this vehicle to extremes in order to develop the most comprehensive suspension components on the market. From the brutal deserts of Baja, to the deep snow of Michigan’s U.P., to the wooded trails of the East coast, ICON suspension systems have been put to the test and consistently perform beyond expectation. Unable to leave “well-enough” alone, ICON is once again aiming to raise the bar in Raptor performance with the introduction of the RXT Rear 3.0 Remote Reservoir Bypass Shock for the 2021-2025 Gen3 F-150 Raptor.

Note: APPLICATION NOTE #150: Shocks are fully serviceable

Watch product video

Products specifications

Attribute name	Attribute value
AAP_UDA_12	EA
AAP_UDA_22	1
AAP_UDA_4	55
Active or Passive Suspension	Active
Add-On Part	252012 - -4 TO -10 HOSE SHIELD KIT, 93500 - 15-23 F150 & 17-22 FSD IIC INSTALL KIT, 95003 - 21-25 F-150 RAPTOR FRONT 3.0 VS RR CDEV COILOVER KIT, 95230 - 21-25 F-150 RAPTOR TRIPLE RATE REAR COIL SPRING KIT, 95231 - 21-25 F-150 RAPTOR TRIPLE RATE OVERLAND REAR COIL SPRING KIT, 95206L - 21-25 F-150 RAPTOR DRIVER REAR 3.0 ZETA RR CDEV, 95020 - 21-25 F-150 RAPTOR SOLENOID MOUNT KIT
Adjustable	Yes
Adjustable Compression	Yes
Adjustable Damping	Yes
Adjustable Rebound	Yes
Adjustable Ride Height	No
Body Color	Gray
Body Diameter	3
Body Material	Steel
Boot Included	Yes
Bore Diameter	2.75
Bypass Tube Quantity	3
Bypass Type	External
California Prop 65 Warning	Yes
California Proposition 65	WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Color	Black, Gray, Silver
Cylinder Color	Gray
Cylinder Finish	Ceramic Coated
Cylinder Material	Steel
Cylinder Outside Diameter	3
Damping Adjustment Type	Electronic, Manual
Damping Type	Oil
Dust Shield	Yes
Dust Shield Included	Yes
Dust Shield Material	Polyurethane
External Reservoir	Yes
Finish	Ceramic Coated
Gas Charged	Yes
Grade Type	Performance
Hydraulic Lockout	No
Includes Bump Stop	No
Internal Construction Type	Single Tube
Internal Rebound Bumper	No
Internal Rebound Spring	Yes
Lower Mount Sleeve Inside Diameter	.475
Lower Mount Sleeve Overall Length	1.46
Lower Mount Type	Loop (Eyelet) Bearing
Material	Aluminum, Steel
Maximum Ride Height Raising Distance	1
Minimum Ride Height Raising Distance	0
Mounting Hardware Included	Yes
Remote Reservoir	Yes
Reservoir Diameter	3
Reservoir Hose Inside Diameter	.5
Reservoir Hose Length	21.5
Reservoir Length	12.5
Reservoir Type	Remote
Rod Diameter	1
Self-Leveling	No
Service Parts	252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0), 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL, 302005 - 3.0 ICON REBUILD KIT (ALL), 252003 - SEAL INSTALL TOOL 2.5/3.0
Shaft Diameter	1
Shaft Material	Chrome
Shock Absorber Body End Measuring Point	CENTER OF EYELET
Shock Absorber Bore Size	2.75
Shock Absorber Rod End Measuring Point	CENTER OF EYELET
Suspension Type	Spring
Type	Telescopic
Upper Mount Sleeve Inside Diameter	.475
Upper Mount Sleeve Overall Length	1.46
Upper Mount Type	Loop (Eyelet) Bearing
Valving Type	Digressive, Linear, Position Sensitive, Velocity Sensitive
Country of Origin	US
Condition	New
