Spicer Drive Shaft - 350CS54003-1225M

Name: Spicer Drive Shaft - 350CS54003-1225M
SKU: 350CS54003-1225M
Availability: InStock

Coupling Shaft XL

Manufacturer: Spicer

Manufacturer part number: 350CS54003-1225M

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Prop 65	NO
Series	SPL350
Tube Length (In)	48.2283
Tube Length (Mm)	1225.0000
Tube Size (IN)	5.4600 x 0.1670
Tube Size (Mm)	138.6000 x 4.2500
Phased - Degrees	90.0000
Unwelded/Welded Assembly	Welded
Shaft Material	Steel
CL Yoke To CL Yoke (IN) - COLL	60.9921
CL Yoke To CL Yoke (MM) - COLL	1549.2000
CL Yoke To CL Bearing (MM)	1393.0000
CL Yoke To CL Bearing (IN)	54.8425
Phased (Yes/No)	Yes
1/2 Max Slip (MM)	55.0000
Country of Origin	US
Condition	New
