Spicer Drive Shaft - 908191-3

Name: Spicer Drive Shaft - 908191-3
SKU: 908191-3
Availability: InStock

Short Couple Drive Shaft

Manufacturer: Spicer

Manufacturer part number: 908191-3

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Prop 65	Yes
California Proposition 65	! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Series	1810
Phased (Yes/No)	No
CL Yoke To CL Yoke (MM) - COLL	221.1000
Mid Slip (MM)	14.2000
Mid Slip (IN)	0.5591
FF(Flange Face) To FF (MM)-COLL	392.9000
Slip Assembly	No
1/2 Max Slip (MM)	14.2000
Phased - Degrees	0.0000
Unwelded/Welded Assembly	Unwelded
Notes	Short Couple
CL Yoke To CL Yoke (IN) - COLL	8.7047
End 1 Type SJ Side	6.5 - 2 - 329
CV Joints Included	No
End 2 TJ Side	6.5-2-329
CL Yoke To Flange Face (MM)-COLL	307.0000
CL Yoke To Flange Face (MM)-INST	321.2000
CL Yoke To Flange Fac e(IN)-COLL	12.0866
FF(Flange Face) To FF (IN)-INST	16.0276
FF(Flange Face) To FF (MM)-INST	407.1000
1/2 Max Slip (IN)	0.5591
Shaft Material	Steel
Max Slip (IN)	1.1181
Max Slip (MM)	28.4000
FF(Flange Face) To FF (IN)-COLL	15.4685
Country of Origin	US
Condition	New
