Spicer Select Universal Joint - 25-4326X

Name: Spicer Select Universal Joint - 25-4326X
SKU: 25-4326X
Availability: InStock

Universal Joint Greaseable Mechanics 7 Series 2 HWD

Manufacturer: Spicer Select

Manufacturer part number: 25-4326X

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Choosing aftermarket products does not have to mean taking a chance on Quality. Spicer Select Aftermarket Drivetrain Products are Dana-engineered to provide dependable performance. More than 100 years of expertise is proof-positive that we get the job done right, so you can keep doing yours.

Products specifications

Attribute name	Attribute value
Material	Steel
Bearing Cap Diameter (1)	1.625
OEM Mfg	Mechanics
OEM Series	Mechanics 7
Type	ISR/WB Style
Pilot Diameter	5.844
Distance Between Bolts (2)	1.969
Wb Type (2)	HWD
Bearing Cap Type	Round with ISR Groove X Wing
Snap Ring Included	Yes
Snap Ring Type	Internal
Grease Zerk Included	Yes
Pre-Greased	No
Grease Fitting Location	Side of Cross
Greaseable	Yes
Bearing Cap Diameter A (mm)	41.300
Bearing Cap Type A	ISR
Bearing Cap Type B	HWD
Hardware Included	No
Length A (In)	4.620
Length A (mm)	117.348
Mounting Hardware Included	No
Prop 65	NO
Distance Btw Snap Ring Grooves	4.620
Wing Bearing Type	HWD
Wing Bearing Type Pilot Diam.	5.844
Country of Origin	US
Condition	New
