Bilstein Suspension Shock Absorber - 33-230313

Check if this part fits your vehicle Select your vehicle to confirm fitment before you buy.

Select vehicle
B8 5125 - Suspension Shock Absorber
Manufacturer: Bilstein
Manufacturer part number: 33-230313
Old price: $164.00
$118.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Bilstein B8 5125 shock absorbers are designed for custom applications and are a perfect solution for vehicles that do not have a direct Bilstein fitment. These high gas pressure monotube shock absorbers are sold by various lengths and valve rates to accommodate a wide range of uses and custom fitments. All B8 5125 shock absorbers come equipped with industry standard 5/8 inch hour glass bushings and are available in either an eye/eye or stem/eye mount configuration. The shock absorbers feature a 46mm piston with self-adjusting deflective disc valving. Bilstein B8 5125 shock absorbers are the ideal choice for custom suspension builders.

Products specifications

Attribute name Attribute value
Internal Design Monotube
Collapsed Length (IN) 13.66
Mount Type Eye-to-Eye
Lower Mount Type Eye 5/8in
Finish Zinc Plated
Upper Mount Type Eye 5/8in
Boot Included Black Bellows
Body Design Smooth Body (Non-Coilover)
Reservoir No
Series B8 5125
Adjustable Damping Non-Adjustable
Spring Seat Included No
Segment Light Truck
PartType Shocks / Struts
Prop 65 Y/N Y
Prop 65 - Short Label WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Rebound @0.52m/s 1810
Extended Length (mm) 551.2
Compression @0.52m/s 595
Extended Length (IN) 21.70
Piston Diameter 46mm
Collapsed Length (mm) 347.0
Shaft Diameter 14mm
Stroke/Travel Length (mm) 204.2
Stroke/Travel Length (IN) 8.04
Country of Origin MX
Condition New
Quantity per Application 2
🚗 Compatible with
19 vehicles are compatible with this product · 1976–1986
