Bilstein Suspension Shock Absorber - B46-1103R06

M 7100 (Coilover) - Suspension Shock Absorber
Manufacturer: Bilstein
Manufacturer part number: B46-1103R06
Old price: $232.00
$0.01
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Bilstein M 7100 (Coilover) is designed for custom off-road motorsports and recreational applications. These coilovers are owner rebuildable and are available in remote reservoir or non-reservoir configurations. Each coilover is supplied with ½ inch heims and misalignment spacers for maximum durability in off-road conditions. M 7100 (Coilover) is offered in a 10 inch travel stroke with a choice of multiple valve settings and will accommodate a 2.5 inch ID coil spring. All service components are readily available and sold separately. M 7100 (Coilover) is the perfect choice for light weight off-road vehicles.

Products specifications

Attribute name Attribute value
Reservoir Yes
Lower Mount Type 1/2in Heim
Extended Length (mm) 676.9
Upper Mount Type 1/2in Heim
Body Design Threaded Body (Coilover)
Rebound @0.52m/s 3600
Collapsed Length (IN) 17.44
Internal Design Monotube
Finish Nickel Plated with Clear Powder Coat
Mount Type Eye-to-Eye
Optional Reservoir Clamp N/A
Series M 7100 (Coilover)
Extended Length (IN) 26.65
Compression @0.52m/s 800
Spring Seat Included Yes
Segment Motorsports
PartType Shocks / Struts
Prop 65 Y/N Y
Prop 65 - Short Label WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Spring Hardware Single Rate (2.5in)
Piston Diameter 46mm
Collapsed Length (mm) 443.0
Shaft Diameter (mm) 14.0
Stroke/Travel Length (mm) 233.9
Stroke/Travel Length (IN) 9.21
Country of Origin US
Condition New
Quantity per Application 2
