Bilstein Suspension Shock Absorber - F4-BE5-H913-M1

Name: Bilstein Suspension Shock Absorber - F4-BE5-H913-M1
SKU: F4-BE5-H913-M1
Price: 0.01 USD
Availability: OutOfStock

SLS-M Series - Suspension Shock Absorber

Manufacturer: Bilstein

Manufacturer part number: F4-BE5-H913-M1

Old price: $170.50

Price: $0.01

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Bilstein SLS-M Series shock absorbers feature a 46mm piston, steel construction, and a smooth body designed for motorsports applications. These shock absorbers are available in a variety of lengths, valve settings and can be converted to a coilover design (kit sold separately). SLS-M Series shock absorbers are ideal for racers whose sanctioning rules do not allow or require rebuild capability.

Products specifications

Attribute name	Attribute value
Extended Length (IN)	23.52
Upper Mount Type	1/2in Heim
Valving Identifier	1.5-5M
Collapsed Length (IN)	14.88
Boot Included	No
Internal Design	Monotube
Adjustable Damping	Non-Adjustable
Compression @0.26m/s	1210
Extended Length (mm)	597.5
Finish	Zinc Plated
Series	SLS-M Series
Body Material	Steel
Rebound @0.26m/s	460
Body Design	Smooth Body (Non-Coilover)
Piston Type	Linear
Lower Mount Type	1/2in Heim
Spring Seat Included	No
Segment	Motorsports
PartType	Shocks / Struts
Prop 65 Y/N	Y
Prop 65 - Short Label	WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Spring Hardware	B4-BOA-0000117
Piston Diameter	46mm
Collapsed Length (mm)	381.0
Shaft Diameter	14mm
Stroke/Travel Length (mm)	219.5
Stroke/Travel Length (IN)	8.64
Country of Origin	US
Condition	New
Quantity per Application	2
