CLYMER MANUAL, OMC COBRA SX & DPS 1994-200

574 pages

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Before each use / After each use / Lubrication / Fuel system maintenance / Engine coolant / Tune-up / Submersion / Specifications

CHAPTER FOUR / LAY-UP, WINTERIZING AND FITTING OUT
Lay-up / Winterizing / Fitting out

CHAPTER FIVE / ADJUSTMENTS
Carburetor adjustment / Ignition timing adjustment / Shift cable adjustment / Throttle cable adjustment / Trim position sender and trim limit control module adjustment / Specifications

CHAPTER SIX / ENGINE
Engine operation / Special tools / Replacement parts / Special service precautions / Engine removal / Engine installation / Engine alignment / Rocker arm cover / Valve adjustment / Placing the No. 1 piston at TDC (firing position) / Lifter cover / Measuring camshaft lobe lift / Cylinder head / Valves and valve seats / Rocker arm and pushrod / Flywheel housing, drive coupler and flywheel / Oil pan / Oil pump / Harmonic balancer / Timing gear or chain cover and oil seal / Timing chain and sprockets / Balance shaft / Camshaft and lifters / Piston and connecting rod / Crankshaft and rear main seal / Break-in procedure / Specifications

CHAPTER SEVEN / FUEL SYSTEM
Servicing the fuel system / Mechanical low-pressure fuel pump / Low-pressure electric fuel pump / Flame arrestor and cover / Carburetor / Electronic fuel injection (EFI) / Throttle body / Intake plenum, fuel rail and injectors / Fuel pressure regulator / High-pressure electric fuel pump / Fuel reservoir / Intake manifold / Specifications

CHAPTER EIGHT / COOLING AND EXHAUST SYSTEMS
Thermostat / Hose replacement / Recirculation pump replacement / Seawater pump / Oil and power steering fluid coolers (replacement) / Exhaust elbow / Exhaust bellows, exhaust tube and flapper valve / Exhaust manifold / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Battery / Alternator / Starter and starter solenoid / Ignition system / Starter slave solenoid / Starter relay / Fuel pump relay / Electronic fuel injection (EFI) system relay / Oil pressure sender / Oil pressure switch / Coolant temperature sender / Coolant temperature sensor / Engine overheat switch / Manifold air pressure sensor / Intake air temperature (IAT) sensor / Throttle position sensor (TPS) / Idle air control motor (IAC) / Idle speed control solenoid (ISC) / Knock sensor (KS) / Knock sensor module / Knock sensor amplifier / Engine control unit (ECU) / Engine control assembly (ECA) / Specifications

CHAPTER TEN / DRIVE UNIT
Drive unit identification / Drive unit operation / Drive unit gear ratio / High altitude operation / Outdrive service precautions / Sacrificial anodes / Shifting and propeller rotation / Propeller / Drive unit / Universal joint service / Shift housing service / Lower gearcase / Drive unit pressure and vacuum tests / Specifications

CHAPTER ELEVEN / TRANSOM BRACKET
Pivot housing / Bellows and water hose / Gimbal bearing and seal / Gimbal ring / Inner transom plate and bracket housing / Specifications

CHAPTER TWELVE / POWER TRIM SYSTEM
Electrical trim system components / Hydraulic trim system components / Trim cylinder and hoses / Trim position sender / Filling and bleeding the trim system / Specifications

CHAPTER THIRTEEN / STEERING SYSTEM
Safety precautions / Mechanical (manual) steering system / Power steering system / Specifications

INDEX

COLOR WIRING DIAGRAMS

Models covered:
1994 1995 19961997 1998 1999 2000 OMC 3.0GL
1994 1995 1996 1997 1998 1999 2000 OMC 3.0GS
1994 1995 1996 1997 1998 1999 2000 OMC 4.3GI
1994 1995 1996 1997 1998 1999 2000 OMC 4.3GL
1994 1995 1996 1997 1998 1999 2000 OMC 4.3GS
1994 1995 1996 1997 1998 1999 2000 OMC 5.0FI
1994 1995 1996 1997 1998 1999 2000 OMC 5.0FL
1994 1995 1996 1997 1998 1999 2000 OMC 5.0FSI
1994 1995 1996 1997 1998 1999 2000 OMC 5.0GI
1994 1995 1996 1997 1998 1999 2000 OMC 5.0GL
1994 1995 1996 1997 1998 1999 2000 OMC 5.7GI
1994 1995 1996 1997 1998 1999 2000 OMC 5.7GL
1994 1995 1996 1997 1998 1999 2000 OMC 5.7GS
1994 1995 1996 1997 1998 1999 2000 OMC 5.8FI
1994 1995 1996 1997 1998 1999 2000 OMC 5.8FL
1994 1995 1996 1997 1998 1999 2000 OMC 5.8FSI
1994 1995 1996 1997 1998 1999 2000 OMC 7.4GI
1994 1995 1996 1997 1998 1999 2000 OMC 7.4GL
1994 1995 1996 1997 1998 1999 2000 OMC 7.4GSI
1994 1995 1996 1997 1998 1999 2000 OMC 8.2GI
1994 1995 1996 1997 1998 1999 2000 OMC 8.2GL
1994 1995 1996 1997 1998 1999 2000 OMC 8.2GSI

Manufacturer Part #: CB739

Prop 65 WARNING: This product can expose you to chemicals known to the State of California to cause cancer and/or reproductive harm. For more information go to www.P65Warnings.ca.gov.
