Hella Spade Terminal - 178042122

Name: Hella Spade Terminal - 178042122
SKU: 178042122
Availability: InStock

Manufacturer: Hella

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

HELLA Spade Terminal 178042122

Products specifications

Attribute name	Attribute value
California Proposition 65 Required	No
Temperature range from [°C]	-40
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Cross Section [mm²] from	1.5
Quantity	100
Temperature range to [°C]	105
Cross Section [mm²] to	2.5
Temperature range to [°F]	221.00
Length [mm]	24.7
Current Strength to [A]	27
DIN/ISO Standard	46237
Bore Diameter [mm]	5.3
Bore Ø [mm]	5.3
Voltage to [VDC]	600
Container Type	Blister Pack
Color	Blue
Material	Copper
Plug Type ID	M5
Insulation Material	Nylon
Plug Type	Ring Connector
Version	Standard
Surface	Tin-Plated
