JE Pistons Engine Piston Kit - 360825

Name: JE Pistons Engine Piston Kit - 360825
SKU: 360825
Price: 345.00 USD
Availability: OutOfStock

Pressure Plate:Diaphragm: 12" Ford Long Pattern: #2250 :Ford

Manufacturer: JE Pistons

Manufacturer part number: 360825

Old price: $431.25

Price: $345.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

McLeod Racing makes quality performance pressure plates for a wide variety of vehicles--domestic, imported, new, classic, you name it. We manufacture diaphragm, Borg & Beck, and Long types, with both aluminum and ductile-iron pressure rings. Not only that, we have applications designed for drag racing, road racing, oval tracks, and even the fabled dry lakes and salt flats of California, Nevada, and Utah. Chances are, we have what you need!

Products specifications

Attribute name	Attribute value
Piston Series	JE Pistons
Cylinder Head	GEN 5 LT1
Compression Ratio	10.00:1 / 59.00 CC Head
Oversized Amount	0.005
Product Type	Engine Piston Kit
Category Hierarchy	Auto>All Piston Kits
Bore Diameter	4.070
Piston Head Type	Dish
Compression Height	1.326
Piston Volume	-14.10
Material	2618
Piston Quantity	8
Forging Type	FSR
Piston Average Weight	474
Ring Set Included	Yes
Top Compression Ring Thickness	0.0480
Second Compression Ring Thickness	0.0600
Oil Ring Thickness	0.1175
Wrist Pin Included	Yes
Wrist Pin Part Number	943-2250-20-51C
Wrist Pin Material	5115 Low Carbon Steel, Case Hardened
Wrist Pin Outer Diameter	0.943
Wrist Pin Length	2.250
Wrist Pin Wall Thickness	0.200
Wrist Pin Retainer Included	Yes
Wrist Pin Retainer Part Number	927-073-MW
Engine Displacement	377
Engine Stroke	3.622
Connecting Rod Length	6.098
Deck Height	9.240
Ring Set Thickness	1.20 MM x 1.50 MM x 3.00 MM
Oversized	Yes
Ring Set - Recommended	JG31F1-4070-0
OEM Bore Diameter	4.065
Piston Sub-Series	LT1 (Gen V)
Engine Family	LS
Prop 65 (C, R or CR)	CR
Prop 65 Yes/No	Yes
Prop 65 - Short Label	prop65warninglabel.jpg
Bore Diameter - Web	4.070 IN
EBAY Category ID	33623
Application	Ford Big Block 429-460; 332-428 BB Fe
Pressure Plate Diameter (in.)	12.000
Pressure Plate Pattern	Ford Long Pattern
Bolt Circle	3-9/16
Clamp Load	2250 Lbs
Counterweight Assist	No
Bolt Holes Dia	5/16 x 18
Dowel Pins Required	No
Hardware Included	No
SFI Approved	Yes
Note	Comes With Mechanical Bearing for 1-3/8 x 10 Inputshaft
Country of Origin	US
Condition	New
