Bilstein Suspension Shock Absorber - 24-313636

Name: Bilstein Suspension Shock Absorber - 24-313636
SKU: 24-313636
Price: 109.42 USD
Availability: InStock

AK Series - Suspension Shock Absorber

Manufacturer: Bilstein

Manufacturer part number: 24-313636

$109.42

PRICE BREAKS - The more you buy, the more you save

Quantity	2+
Price	$103.10

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Bilstein AK Series Suspension Shock Absorbers are designed for motorsports applications that require the use of the OE mounting components. Each Suspension Shock Absorber features a monotube design with steel spring valve discs for consistent, fade free performance and superior durability. AK Series Suspension Shock Absorbers are ideal for racers who demand reliable performance that also meets their sanctioning body's mounting requirements.

Application: No Applications

Products specifications

Attribute name	Attribute value
Rebound @0.52m/s	1185
Collapsed Length (IN)	13.11
Extended Length (IN)	20.28
Extended Length (mm)	515.0
Compression @0.52m/s	835
Series	AK Series
Upper Mount Type	Bar Pin
Boot Included	Blue Straight
Lower Mount Type	Cantilever
Piston Type	Digressive
Internal Design	Monotube
Spring Seat Included	No
Adjustable Damping	Non-Adjustable
Body Material	Steel
Body Design	Stock Mount Smooth Body
Finish	Yellow Paint
Segment	Motorsports
PartType	Shocks / Struts
Prop 65 Y/N	Y
Prop 65 - Short Label	WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Piston Diameter	46mm
Collapsed Length (mm)	333.0
Shaft Diameter	11mm
Stroke/Travel Length (mm)	182.1
Stroke/Travel Length (IN)	7.17
Country of Origin	MX
Condition	New
