Spicer Automatic Transmission Output Shaft Flange - 5-1-5121X

Name: Spicer Automatic Transmission Output Shaft Flange - 5-1-5121X
SKU: 5-1-5121X
Availability: InStock

Automatic Transmission Mission; Output Shaft; Companion Flange

Manufacturer: Spicer

Manufacturer part number: 5-1-5121X

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Series	1610
Material	Steel
Spline Count	34 I
Involute Spline	Y
Prop 65	NO
Companion Flange Assembly	Y
Flange Face To End Of Hub (G)	3.938
Ground Hub Diameter In.	2.562
Length Thru Hole (F) In.	2.781
Major Diameter (D) In.	1.790
Pilot Diameter (C) In.	6.625 - FEMALE
Bolt Circle Dia.(B) In.(FL YK)	6.125
Bolt Hole Diameter In (FL YK)	0.375 - DRILLED
Number Of Holes (FL YK)	8
Country of Origin	US
Condition	New
