Spicer Drive Shaft End Yoke - 2-4-783-1

Name: Spicer Drive Shaft End Yoke - 2-4-783-1
SKU: 2-4-783-1
Availability: OutOfStock

1310 SERIES END YOKE

Manufacturer: Spicer

Manufacturer part number: 2-4-783-1

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Spicer end yokes deliver the same quality and reliability you expect from your original equipment parts. That is because they are OE parts, manufactured to the same standards and specifications as the end yokes that were installed in your vehicle in the first place.

Products specifications

Attribute name	Attribute value
Series	1310
Material	Steel
Type	Straight Round Hole
Hub Diameter R	2.120
Involute Spline	N
Length Thru Hole Q	1.495
Outside Yoke Dimension In.(E)	3.219
Yoke Bearing Dimension (In) D	1.062
Yoke Style	BS
C/L To End Hub S	2.935
Joint Angle #1	22
Prop 65	NO
Hole Diameter (In) P	1.250
Keyway Location W	12
Sae Keyway Width (In) X	0.314
Set Screw Location W	6
Set Screw Hole Diameter (In)	0.375
Hole Diameter - Max	1.2505
Hole Diameter - Min	1.2495
Keyway Width - Max	0.3155
Keyway Width - Min	0.3135
Country of Origin	US
Condition	New
