Spicer Drive Shaft Midship Stub Shaft - 2-53-1351

Name: Spicer Drive Shaft Midship Stub Shaft - 2-53-1351
SKU: 2-53-1351
Availability: OutOfStock

DRIVE SHAFT MIDSHIP STUB SHAFT

Manufacturer: Spicer

Manufacturer part number: 2-53-1351

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Thread Size	.625-18
Style	2
Prop 65	NO
Spline O.D.	1.125
Spline Length (L) In	1.375
Bearing Diameter (Min)	1.181
For Use With	End Yoke Or Companion Flange
Shoulder Diameter (B) In.	1.181
Shoulder Length (G) In.	.665
Spline End To Brg Shoulder (Y)	1.906
Fits Tube Diameter	2.500
Involute	Y
Fits Tube Wall	.083
Butt Diameter	2.345
Bearing Diameter (C) In.	1.181
Bearing Diameter (Max)	1.1815
Spline End To Weld (K) In.	3.406
Number of Splines	26 I
Country of Origin	MX
Condition	New
