Spicer Drive Shaft Transmission Slip Yoke - 2-3-15871X

Name: Spicer Drive Shaft Transmission Slip Yoke - 2-3-15871X
SKU: 2-3-15871X
Availability: InStock

Drive Shaft Transmission Slip Yoke

Manufacturer: Spicer

Manufacturer part number: 2-3-15871X

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Series	1330
Material	Steel
Style	SR
Prop 65	NO
No. Of Splines	30/32 I
Bearing Cap Diameter (D) In.	1.062
Outside Yoke Dimension (E) In.	3.875
Spline O.D. (STD)	1.378
To End Of Spline (J) In.	6.102
Type of Hub	Ground Hub
C-Line to Washer Face	1.128
Involute	I
Number of Splines Based On	32
Counter Bore Depth	.393
Counter Bore Diameter	1.375
Spline O.D. (MM)	35
Hub Diameter (R) In.	1.731
Country of Origin	US
Condition	New
